Locked, shown in Figure 6-19.

6.2.1.7 Engine Configuration

The Engine configuration is accessed from the System Config sub-menu, Figure 6-8, refer to Section 6.2
and the current Engine configuration selection is shown on the Engine button.
THE DEFAULT SELECTION IS SINGLE ENGINE. WHEN THE INDICATOR SHOWS MULTI, THE
KSD 100EXP WILL DISPLAY ADDITIONAL V-SPEED PARAMETERS: MINIMUM CONTROL
SPEED (V ) AND BEST RATE OF CLIMB SPEED (V
MC
(1) Press the Engine button to toggle from Single to Multi, shown in Figure 6-20.
(2) Press the Back-Arrow button to exit the System Config sub-menu and return to the Installer Main
Menu, Figure 6-7.

6.2.1.8 Units Configuration

The Units configuration is accessed from the System Config sub-menu, Figure 6-8, refer to Section 6.2 and
the current Unit configuration selection is shown on the Units button.
THE DEFAULT UNIT SELECTION IS KNOTS (KT). THE UNITS USED ON THE KSD 100EXP MUST
BE SET TO THE SAME UNITS PUBLISHED IN THE AIRPLANE FLIGHT MANUAL (AFM).
(1) Press the Units button to toggle between Knots (KT) and Miles per Hour (MPH), shown in Figure 6-
21.
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft

Figure 6-19 Pilot V-Spd Locked/Unlocked Toggle

NOTE

Figure 6-20 Engine Configuration

NOTE

Figure 6-21 Units Configuration

).
YSE
xVue Touch Installation Manual
Page 6-15
