3.5 System Interfaces

3.5.1 Standard Interface Definitions

Unless otherwise stated, the following interface definitions will apply.

3.5.1.1 Discrete I/O

3.5.1.1.1 Discrete Inputs

Refer to the tables below for the discrete input states.

Table 3-15 KSD 100EXP Discrete Input Ground/Open (DIGO) States

State
Active
Inactive

Table 3-16 KSD 100EXP Discrete Input 5V/Open (DI5VO) States

State
Active
Inactive

Table 3-17 KSD 100EXP Discrete Input 15V/Open (DI5VO) States

State
Active
Inactive

Table 3-18 KSD 100EXP Discrete Input 28V/Open (DI28VO) States

State
Active
Inactive
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Voltage Level
0 VDC
Open Circuit
Voltage Level
5 VDC
Open Circuit
Voltage Level
15 VDC
Open Circuit
Voltage Level
28 VDC
Open Circuit
