Chapter G: Ball Phantom; Setting Up For A Ball Phantom - Planmeca ProMax Pan/Ceph Calibration Manual

Chapter
G
1 Setting up for ball phantom
Place the ball phantom in the patient positioning mechanism. (Figure 57)
NOTE: Layer must be at 0mm before doing a ball phantom. If layer is not then adjust the thumb wheel till
layer is at 0mm. (Figure 58)
Printed copies of this document are considered uncontrolled.
22811.20.Rev001 07.31.2018
Ball Phantom
Figure 57
Figure 58
