6
Fixed Sensor Holder
Pull back on the inner cover of the sensor holder. (Figure 13)
Unscrew the two screws on the top of the rear cover of the holder with a 2.5mm allen.
(Figure 14)
Printed copies of this document are considered uncontrolled.
22811.20.Rev001
07.31.2018
Figure 13
Figure 14
- 14 -
14
