Chapter F: Calibration; Dimax3 Tool - Planmeca ProMax Pan/Ceph Calibration Manual

Chapter
F
Press Done and Exit
Close Beam Check and open Dimax3 Tool
1

Dimax3 Tool

Click on Start, All Programs, Planmeca then Dimax3 Tool. (Figure 51)
Click on Calibrate and select Pan. (Figure 52)
Follow the instructions on the computer screen.
Printed copies of this document are considered uncontrolled.
22811.20.Rev001 07.31.2018
Calibration
Figure 51
Figure 52
- 35 -
35
