M o d e - M
PAGE-2
M o d e - M
As shown above, in the first page, line-2 shows the fault code, line-3 shows the DC Bus Voltage &
Output Current and line-4 shows the Output Frequency & Heat sink Temperature. In the second page
also, line-2 shows the fault code, line-3 shows Input Voltage (Vry) & Total Conductivity Time (Hr) and
line-4 shows the Energy Meter (MWH & kWH). If no fault is detected since shipment, line-2 in both the
pages will display "No previous fault" and the value of different parameters will be read as zero.
6
Same way FLT-2 ~ FLT10 shows the previous fault codes and parameters at the time of fault
occurrence.
GROUP-6
M601 ~ M624: Output Current of U, V, W phase and Inverter Unit Current
These parameters display the Output current of U, V and W phase of Inverter Unit 1 to 6, whereas,
parameters M604, M608, M612, M616, M620 and M624 display output current of Inverter Unit 1 to 6.
M621, M622, M623 and M624 parameters are applicable when PCA-2049A parallel interface board is
used in the drive.
GROUP-7
M701: Control Version Parallel Inverter
Indicate ROM version of DSP Based interface board PCA-2013A/PCA-2049A for parallel inverter.
M702: Temperature Inverter Unit (IU) – 2 (° C)
M703: Temperature Inverter Unit (IU) – 3 (° C)
M704: Temperature Inverter Unit (IU) – 4 (° C)
M705: Temperature Inverter Unit (IU) – 5 (° C)
These parameters display the actual heat sink temperature of Inverter Unit 2 to 5. The value will be
displayed with "° C" unit.
M706: Temperature Diode Unit (DU) – 1 (°C)
Amtech
6-42
F L T - 1
E x t e r n a l
5 8 5 V d c
1 0 . 0 0 H z
F L T - 1
E x t e r n a l
4 2 0 V r y
1 1 0 M W H
G r o u p - 4
F a u l t
0 . 0 A m p
3 5 ° C
G r o u p - 4
F a u l t
6 0 1 1 0 H r
7 3 5 k W H
