MODE-D: Auxiliary Drive Parameters
No. Parameter
GROUP-1: MOTOR PARAMETERS
D101 Motor Voltage
D102 Motor Current
D103 Motor Frequency
D104 Motor Speed
D105 Motor Output
Rating
GROUP-2: FREQUENCY SETTING
D201 Local Set
Frequency
D202 Min Frequency
6
D203 Max Frequency
D204 Frequency
Reference Input
D205 Line Speed Setting rpm
D206 Acceleration Time-
1
D207 Deceleration Time-
1
GROUP-3: TORQUE BOOST
D301 Manual Torque
Boost
Setting
D302 Slip Compensation
D303 DC Brake Start
Frequency
D304 DC Brake Current
Amtech
6-24
Unit Def Min Max
Vac 415 380 480
575 500 575
690 600 690
230 200 240
Amp M304 0.3* M304
M304
Hz 50.0 10.0 600.0
rpm 1500 1 36000
kW M305 0.1 1500.0
Hz 10.00 0.00 600.00
Hz 0.10 0.00 600.00
Hz 50.00 0.10 600.00
1 1 18
1500 0 3000
Sec 10.0 0.1 6000.0
Sec 20.0 0.1 6000.0
% 0 0.0 20.0
Hz 0.0 0.0 5.0
Hz 1.50 0.00 50.00
% 50 15 150
Res Description
1 This is the Motor rated Voltage. Set the voltage
mentioned on the motor nameplate. The setting
value depends on the 400V, 500V, 600V or
200V Series model.
0.1 Insert the rated motor current from the
nameplate.
0.1 Set the rated base frequency from the
nameplate.
1 Set the base speed from the motor nameplate.
0.1 The motor's rated output at the base speed is
set from the nameplate.
0.01 This is the frequency set from the operation
panel for auxiliary motor.
0.01 These two Parameters are used to configure
Minimum and Maximum Frequency of the AC
0.01
DRIVE for auxiliary motor.
1 This is used to select the speed reference for
auxiliary drive.
=1: Local
=3: FSI 4-20mA
=5: FSI 0-20mA
=7: FSI 20-4mA
=9: FSI 20-0mA
=11: Serial
=13: VIN 0-10V
=15: PLC A-O/P 1
=17: PLC A-O/P 3
1 The set value will be displayed as motor speed
in M102 at 50Hz when auxiliary drive is
selected.
0.1 Time needed for the speed to change from zero
to maximum.
0.1 Time needed for the speed to change from
maximum to zero.
0.1 When setting manually, set the boost voltage at
0Hz as a percentage in respect to the rated
output voltage. When programmed to zero, it
will be disabled. This is automatically adjusted
by the automatic tuning.
0.1 Set the motor's rated slip. When setting
manually, set the slip frequency for the motor
rated load in respect to the base frequency. The
output frequency changes according to the
motor rated torque.
0.01 It is a frequency at which DC braking is initiated
during stop.
1 Configure amount of current available for the
DC braking when DC braking is used during
stop.
WP
=2: FSV 0-10V
=4: FSV 0-5V
=6: FSV 10-0V
=8: FSV 5-0V
=10: Static pot
=12: PID Output
=14: IIN 4-20mA
=16: PLC A-O/P 2
=18: PLC A-O/P 4
