C111 ~ C112: Programmable Relay-1 ~ 2
C113: Programmable Fault Relay
User can configure two programmable relays for different functions using these parameters. The
status of the Programmable Relay can be monitored in M308. The options are same as PSO.
The default settings are as under.
RELAY
Programmable Relay-1
Programmable Relay-2
Programmable Fault Relay
GROUP – 2: ANALOG OUTPUT SELECTION
6
C201 ~ C202: Vout-1 ~ 2
User can configure two programmable analog outputs (0~10V) for different functions using
parameters C201 ~ C202.
OPTION
1 Output Freq
2 O/P Current
3 Output Power
4 Output Volt
5 DC Bus Volt
6 PID Output
7 Heat sink Temp.
8 PLC A-O/P 1
9 PLC A-O/P 2
10 PLC A-O/P 3
11 PLC A-O/P 4
12 Unipolar Torque
Current
13 Excitation
Current
14 Set Frequency
15 Bipolar Torque
Current
The default setting of the programmable analog outputs are as under.
TERMINAL
VO1
VO2
Amtech
6-80
6 Freq Attain
1 Not Used
1 Not Used
OPTION
2 Run
1 Not Used
25 Fault
NAME
The analog output will correspond to the output frequency (0~A103).
The analog output will correspond to the output current (0~200%).
The analog output will correspond to the output power (0~B106).
The analog output will correspond to the output voltage (0~100%).
The analog output will correspond to the dc bus voltage (0~800).
The analog output will correspond to the PID Output (0~100%)
The analog output will correspond to the heat sink temp. (0~100 °C)
The analog output will correspond to the PLC A-O/P 1 (0~1000d).
The analog output will correspond to the PLC A-O/P 2 (0~1000d).
The analog output will correspond to the PLC A-O/P 3 (0~1000d).
The analog output will correspond to the PLC A-O/P 4 (0~1000d).
The analog output will correspond to the torque current (0~200%).
The analog output will correspond to the excitation current (0~200%).
The analog output will correspond to the Set frequency (M105).
The analog output will correspond to the torque current (-200~200%).
OPTION NAME
1 Output Freq
2 O/P Current
NAME
FUNCTION
