Amtech Axpert-Eazy Series Instruction Manual page 50

No. Parameter
M624 Output Current6
GROUP-7
M701 Control Version PI
M702 Temperature IU-2
M703 Temperature IU-3
M704 Temperature IU-4
M705 Temperature IU-5
M706 Temperature DU-1
M707 Temperature DU-2
M708 Temperature Panel-1
M709 Temperature Panel-2
M710 Driver Status
M711 Temperature IU-6
M712 Short circuit status IU 1 ~
6
M713 Over current status IU 1-
6
2-3
M714 Over current status IU 4-
5-6
M715 Over temperature Status
IU 1 ~ 6 DU 1 ~ 2
GROUP-8 DEFAULT DIFFER (CHANGE PARAMETERS LIST)
This group provides the change parameters list, only the parameters which differ from default value and user also can
change parameters value from this group. Use UP or DOWN key for next changed parameters.
Amtech
6-4
Unit Res.
Amp 0.1 Display the Output Current of Inverter Unit 6.
0.01 Indicate
ROM
2049A for parallel inverter.
o
C 1 Actual heat sink temperature of Inverter Unit 2 is displayed.
o
C 1 Actual heat sink temperature of Inverter Unit 3 is displayed.
o
C 1 Actual heat sink temperature of Inverter Unit 4 is displayed.
o
C 1 Actual heat sink temperature of Inverter Unit 5 is displayed.
o
C 1 Actual heat sink temperature of Diode Unit 1 is displayed.
o
C 1 Actual heat sink temperature of Diode Unit 2 is displayed.
o
C 1 Actual Inside temperature of Panel 1 is displayed.
o
C 1 Actual Inside temperature of Panel 2 is displayed.
The / state of driver fault status from Inverter Unit (IU) is be
ON OFF
displayed.
o
C 1 Actual heat sink temperature of Inverter Unit 6 is displayed.
The status of short circuit or driver fault from Inverter Unit (IU) is
displayed.
The status of over current fault from individual phase (current sensor)
from Inverter Unit (IU) 1, 2 or 3 is displayed.
The status of over current fault from individual phase (current sensor)
from Inverter Unit (IU) 4, 5 or 6 is displayed.
The status of over temperature fault from thermostat from Inverter Unit
(IU) 1 to 6 and Diode Unit (DU) 1, 2 is displayed.
Description
version of DSP Based interface board PCA-2013A/ PCA-
