GROUP – 6: DISPLAY PARAMETER SELECTION
A601 ~ A608: Normal parameter 1 ~ 8
A601: It selects parameter wishing to display on normal screen position Norm-1 out of M101~M105,
M107, M109~M110, M115~M117, M201~M211, and M217 ~ M219 of monitor mode.
Similarly A602~A608 selects parameters for Norm-2 to Norm-8 positions.
The default setting will be as under.
N o r m
6
Norm 1
Norm 2
F w d , L c l , D r i v e
To display the Output Frequency M101 (Hz) parameter at Norm 1 position as shown in the above
screen, select option 1 (M101 Hz) in parameter A601 Norm Parameter1.
M o d e - A
A 6 0 1
F w d , L c l , D r i v e
Similarly, to display the desired parameters at positions Norm 2, Norm 3 and Norm 4, select the
appropriate option in A602, A603 and A604 respectively.
Parameters A605~A608 selects parameters for Norm-5 to Norm-8 positions for the meter screen and
are not applicable for the normal screen. Below is the meter screen with eight parameters.
Norm 5
Norm 1
Norm 2
Norm 6
GROUP – 7: FREQUENCY REFERENCE MATH OPERATIONS
