Amtech Axpert-Eazy Series Instruction Manual page 124

40 Forward Jog
41 Reverse Jog
42 MBRK Answer
The default selection is as under.
TERMINAL
PSI1
PSI2
PSI3
PSI4
PSI5
PSI6
RUN
STOP
6
C107 ~ C110: PSO-1 ~ 4
User can configure four programmable sequence outputs for different functions using parameters
C107 ~ C110. The status of the Programmable Sequence Output can be monitored in M308. The
various options are explained as under.
OPTION
1 Not Used
2 Run
3 Local
4 Reverse Run
5 I-Detection
6 Freq Attain
7 Speed Detect1
8 Speed Detect2
9 Acceleration
10 Deceleration
11 Aux Drive
12 Timer Output
13 Zero Speed
Amtech
6-78
This is a forward jog command. No need to set extra direction PSI.
(Note: If option 2:JOG or 13:Reverse is selected in any PSI, then
40:Forward Jog PSI is not selected and vice versa).
This is a Reverse jog command. No need to set extra direction PSI.
(Note: If option 2:JOG or 13:Reverse is selected in any PSI, then
41:Reverse Jog PSI is not selected and vice versa).
This is a feedback signal from external brake in response to the
external brake command.
OPTION NAME
2 Jog Select
10 Emergency stop
11 Fault Reset
4 Preset i/p-0
5 Preset i/p-1
6 Preset i/p-2
24 RUN
25 STOP
NAME
No function is selected.
This turns ON during running, jogging or DC braking.
This turns ON when the operation mode is local (operation from the
digital operation panel is selected).
This turns ON when the motor is reverse running.
This turns ON when the output current reaches the programmed I-
Detection Level C302 or higher.
This turns ON when the output frequency (speed) reaches the set
frequency (speed). The detection reach width is set with frequency
attainment detection width C301.
This turns ON when the output frequency (speed) value reaches a speed
higher than the speed set with the detection level –1.
This turns ON when the motor speed reaches a speed higher than that
set in the detection level-2.
This turns ON during acceleration.
This turns ON during deceleration.
This turns ON when the auxiliary drive parameter setting is validated by
the sequence input AUXDV.
This turns ON during running, jogging, pre-excitation and DC braking. A
programmable off delay (C309) is provided, so even if the above
operations turn OFF, this control will not turn OFF for programmed time.
This is used for external fan/ motor control.
This turns ON when the output frequency (speed) value is below the
level set with zero speed level.
FUNCTION
