C315: Fan ON Temperature Level
Set the temperature level to activate the PSO for FAN control.
C316: Fan OFF Hysteresis Level
Set the hysteresis level to de-activate the PSO for FAN control.
C317: External Brake Selection
C318: Brake Release Wait Time
C319: Acceleration Start Wait Time
C320: Brake Engage Wait Time
C321: Run Error Judgment Time At Engaging Brake
6
C322: Brake Answer Error Judgment Time
Parameters C317 ~ C322 used for external brake application.
Select the external brake function using B317.
All types of waiting time
Set the waiting time when using external brake control.
1. Use C318 (Brake Release Wait Time) to set the waiting time from RUN until the brake is
released.
2. Use C319 (Acceleration Start Wait Time) to set the waiting time from the point the brake is
released until acceleration is commenced. When there is a brake answer (C322, Brake Answer
Error Judgment Time
no brake answer (C322, Brake Answer Error Judgment Time = 0), set the waiting time from the
point the brake release command is issued. In the case of the normal operation mode setting,
changes are not made to the settings during C318 wait time, and the settings prior to C318 wait
time are used.
3. Use B320 (Brake Engage Wait Time) to set the waiting time from the point zero speed detection
point turns ON until the brake is engaged.
Error determination
The following error determination can be made in cases of
1. RUN error determination when engaging brake.
In the case where RUN does not turn OFF in the time set at C321 (Run Error Judgment Time At
Engaging Brake) from the time the brake is engaged, a breakdown stop occurs at the end
controller due to an external brake RUN error (Ext Brake RUN Error fault). Set to 0.0 sec to turn
the RUN error determination OFF.
2. Brake answer error determination
In the case where (MBRK) brake command and (MBRK_ans) brake answer do not match above
the time set at C322 (Brake Answer Error Judgment Time), an external brake answer error (Ext
Brake Ans Error Fault) occurs as an external brake breakdown, and a breakdown stop occurs.
Set to 0.0 sec to turn the brake answer error determination OFF.
Amtech
6-86
0 .0 sec), set the waiting time from after the brake answer, and if there is
≠
External Brake Selection is Enable.
