Amtech Axpert-Eazy Series Instruction Manual page 13

Table-2: 500V Series Axpert-Eazy drive (Terminal and applicable wire for Input and Output)
Wire
Rated
AMT-XXX-
size
Current
5
(A)
2
mm
011 20 6
015 23 6
018 30 10
022
37 10
030 46 16
037
54 25
045
73 25
055 87 35
075
110 50
090 135 70
110
150 90
132 175 50 x
2p
160 215 70 x
2p
200 290 90 x
2p
250 345 150 x
2p
315 390 185 x
2p
+
2p = Two parallel
Axpert-Eazy AC Variable Frequency Drive
Lug ID
Lug size
mm
+
max
(inch)
AWG
10 - -
10 - -
8 - -
8 - -
6 - -
4 - -
4 - -
2 - -
1/0 50 x 11.0
M10 (0.43)
2/0 70 x 11.0
M10 (0.43)
3/0 90 x 11.0
M10 (0.43)
1/0 x 50 x 11.0
2p M10 x (0.43)
2p
2/0 x 70 x 11.0
2p M10 x (0.43)
2p
3/0 x 90 x 13.0
2p M12 x (0.51)
2p
250 150 x 13.0
kcmil x M12 x (0.51)
2p 2p
300 185 x 13.0
kcmil x M12 x (0.51)
2p 2p
Terminal
Lug Hole
width
width diameter
mm (inch)
mm mm
(inch) (inch)
I/P O/P
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
18.5 19 (0.75) 10.5 (0.41)
(0.73)
21.4 19 (0.75) 10.5 (0.41)
(0.84)
25.5 19 (0.75) 10.5 (0.41)
(1.0)
18.5 30 (1.18) 11.0 (0.43)
(0.73)
21.4 30 (1.18) 11.0 (0.43)
(0.84)
25.5 40 38 13.0 (0.51)
(1.0) (1.58) (1.50)
31.0 40 38 13.0 (0.51)
(1.22) (1.58) (1.50)
34.2 40 38 13.0 (0.51)
(1.35) (1.58) (1.50)
Tightening
Terminal
torque
screw
N*m
size
(lb-inch)
- - 1.92 (17)
- - 1.92 (17)
- - 1.92 (17)
- - 1.92 (17)
- - 1.92 (17)
- - 4.3 (38)
- - 4.3 (38)
- - 4.3 (38)
M10 22.5 (199)
M10 22.5 (199)
M10 22.5 (199)
M10 22.5 (199)
M10 22.5 (199)
M12 31.2 (276)
M12 31.2 (276)
M12 31.2 (276)
2.5
2
