Amtech Axpert-Eazy Series Instruction Manual page 44

5-7 Default function assignments to terminals
ANALOG INPUT
0-10V Analog Input
Ground
4-20mA Analog Input
0-10V Analog Input
(PID Feedback)
Ground
4-20mA Analog Input
0-10V Analog Output
(Output Frequency)
0-10V Analog Output
(Output Current)
Ground
5
4-20mA Analog Output
(Output Power)
4-20mA Analog Output
(Output Voltage)
ANALOG OUTPUT
SEQUENCE INPUT
Jumper Position
1. The equipment is shipped with sink logic (JP1 is kept on Sink position) for the programmable
sequence inputs. To change the sink logic to source, change the jumper JP1 position to Source.
2. The equipment is shipped with JP3 in NLD position. This means the terminating resistors are not in
picture. To insert the terminating resistors, keep the jumper to LD position.
Amtech
5.6
P15
FSV
0V
FSI
VIN
0V
IIN
VO1
VO2
0V
IO1
IO2
CANH
RESERVE
CANL
Forward Run
RUN
Stop
STOP
Preset Input-2
PSI6
+24V
COM
Jog Select
PSI1
Emergency Stop
PSI2
Fault Reset
PSI3
Preset Input-0
PSI4
Preset Input-1
PSI5
COM
TB1
(Sink logic operation is considered for
programmable sequence inputs in this diagram)
940R
+15V
33k
10k
33k 270R
10k
270R 270R
270R
P
50R
C
A
50R
-
2
0
1
4
A
/
2
0
0
4
A
