No. Parameter
M212 Energy Saved in kW
M213 Energy Saved in MW
M214 Hank Count
M215 Money Saved with VFD
M216 Money Saved with VFD
X1k
M217 Encoder Count
M218 ASR O/P Monitor
M219 ACR O/P Monitor
M220 Drive Overload
M221 Motor Overload
-3
GROUP
6
M301 Total Conductivity Time
M302 Total Run Time
M303 Automatic Tuning display
M304 Rated Current
M305 Inverter Type
M306 Control Version
M307 PSI-12345678 Status
M308 PSO-1234 R-567 Status
M309 Unit Serial Number
M310 Ship Month
M311 Ship Year
M312 Display Version
M313 PLC Display 1
M314 PLC Display 2
M315 PLC Display 3
M316 PLC Display 4
M317 PLC Display 5
M318 PLC Display 6
M319 PLC Display 7
M320 PLC Display 8
M321 PLC Display 9
M322 PLC Display 10
M323 PLC Flag status 0-7
Amtech
6-2
Unit Res.
kWH 1 This parameter displays the saved energy using VFD in kWH.
MWH 1 This parameter displays the saved energy using VFD in MWH.
0.1 Displays the current hank count. The display is limited at a maximum of
6553.5. This is cleared to zero when power is turned off.
1 This parameter displays the money saved with VFD in energy saving
application. Select appropriate currency (B113) and energy cost (B114).
1 This parameter displays the money saved x 1000 with VFD in energy
saving application. Select appropriate currency (B113) and energy cost
(B114).
1 This parameter displays the Encoder count as per below formula.
Encoder Count = (Encoder Pulses (B109)*Motor Speed (M102)*4*
% 0.1 The ASR output is displayed.
% 0.1 The ACR output is displayed.
% 0.1 This parameter displays drive overload in percentage. Drive overload
fault comes when this value reaches to 100%
% 0.1 This parameter displays motor overload in percentage. Motor overload
fault comes when this value reaches to 100%
Hrs 1 The cumulative power on time after product shipment will be counted
and displayed.
Hrs 1 The cumulative AC DRIVE run time after product shipment will be
counted and displayed.
The progression state of automatic tuning is displayed.
A 0.1 This indicates the rated current of the AC DRIVE.
W This indicates the AC DRIVE type.
K
Indicates
ROM
The /
ON OFF
The /
ON OFF
function status) will display.
It displays the serial number of the unit.
It displays the month of unit shipment.
It displays the year of unit shipment.
Indicates
ROM
1 It displays the signed 16-bit register value from the In-built PLC.
1 It displays the signed 16-bit register value from the In-built PLC.
1 It displays the signed 16-bit register value from the In-built PLC.
1 It displays the signed 16-bit register value from the In-built PLC.
1 It displays the signed 16-bit register value from the In-built PLC.
1 It displays the signed 16-bit register value from the In-built PLC.
1 It displays the signed 16-bit register value from the In-built PLC.
1 It displays the signed 16-bit register value from the In-built PLC.
1 It displays the signed 16-bit register value from the In-built PLC.
1 It displays the signed 16-bit register value from the In-built PLC.
1 It displays the status of the PLC flag.
Description
Speed loop time (B601)) / (60*1000)
version of DSP Control Board PCA-2014A.
state of various programmable sequence input will display.
state of various programmable sequence o/p (selected
version of Display Board PCA-2012.
