Amtech Axpert-Eazy Series Instruction Manual page 158

16-bit
Register
No.
94 FSV Input
95 FSI Input
96 Vin Input
97 Iin Input
98-100 Reserved
101 Panel Parameter 1
102 Panel Parameter 2
103 Panel Parameter 3
104 Panel Parameter 4
105 Panel Parameter 5
106 Panel Parameter 6
107 Panel Parameter 7
108 Panel Parameter 8
109 Panel Parameter 9
110 Panel Parameter 10
111 Panel Parameter 11
6
112 Panel Parameter 12
113-114 Reserved
All 100 numbers of 1-bit flags are Read/Write, and one 32-bit register is Read/Write.
In-built PLC Command Format:
The PLC commands used with the In-built PLC are 12- digit value shown in below table. These
commands can be input from the P101 to PA10 parameter.
0 0
OPCODE
Where, OPCODE = Command no.
DATA1
DATA2
DATA3
Note: Range of DATA1, DATA2 and DATA3 are different and it depends on command type. See list of
PLC Commands for detail. It is necessary to terminate program with END (000) Command.
Amtech
6-112
Name Access Type
Read
Read
Read
Read
--
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
Read
2 0 0
DATA1
12-digit In-built PLC Command format
= Data format 1
= Data format 2
= Data format 3
Details
Read input value from FSV
Read input value from FSI
Read input value from Vin
Read input value from Iin
--
Read value set with C701
Read value set with C702
Read value set with C703
Read value set with C704
Read value set with C705
Read value set with C706
Read value set with C707
Read value set with C708
Read value set with C709
Read value set with C710
Read value set with C711
Read value set with C712
1 0 2
DATA2
Value
100d = 100%
100d = 100%
100d = 100%
100d = 100%
--
--
--
--
--
--
--
--
--
--
--
--
--
5 0 0
DATA3
0
