CHAPTER-6: PARAMETER SETTINGS & FUNCTIONS
MODE-M: Monitor Parameters
The monitor parameters display various information like operating parameters, status of various
signals, software version, fault history etc...
No. Parameter
GROUP-1
M101 Output Frequency
M102 Motor Speed
M103 Output Current
M104 Output Current
M105 Set Frequency
M106 Frequency Reference
Input
M107 Set Torque
M108 Torque Reference Input
M109 PID Reference
M110 PID Feedback
M111 FSV Input Voltage
M112 FSI Input Current
M113 VIN Input Voltage
M114 IIN Input Current
M115 Output Current U
M116 Output Current V
M117 Output Current W
GROUP-2
M201 Input Voltage Vry
M202 Input Voltage Vyb
M203 Output Voltage
M204 DC Bus Voltage
M205 Output Power
M206 Energy Meter
M207 Energy Meter
M208 Heat sink Temperature
M209 Torque Current
M210 Excitation Current
M211 Heat sink Temperature
Axpert-Eazy AC Variable Frequency Drive
Unit Res.
Hz 0.01 It displays the output frequency. If the AC DRIVE is off, it will display
zero.
rpm 1 It displays the motor speed or shaft rpm.
If A401=1, 3, 5, 7: It displays the calculated motor speed or shaft rpm
using line speed setting A105 or D205 and M101.
If A401=2, 4, 6, 8: It displays the actual speed of motor shaft using
encoder.
Amp 0.1 It will display the output current. If the AC DRIVE is
zero.
%L 1 The output current is displayed as % of motor rated current B103.
Hz* 0.01 The currently selected frequency setting value is displayed.
The currently selected frequency setting input point in A106 or D204 will
be displayed.
The current value of torque setting is displayed in vector control mode.
% 0.1
The currently selected torque setting input point in A108 will be displayed
in vector control mode only.
0.1 Displays the value of currently selected
in C614.
0.1 Displays the value of currently selected
in C614.
V 0.1 Display the analog input voltage at FSV.
mA 0.1 Display the analog input current at FSI.
V 0.1 Display the analog input voltage at VIN.
mA 0.1 Display the analog input current at IIN.
Amp 0.1 Display the Output current of U phase.
Amp 0.1 Display the Output current of V phase.
Amp 0.1 Display the Output current of W phase.
Vac 1 Displays Input Vry Voltage. This may differ from the actual i/p voltage.
Vac 1 Displays Input Vyb Voltage. This may differ from the actual i/p voltage.
Vac 1 Displays output voltage command. The display may differ from the actual
output voltage. It depends on the power supply voltage. It will display
zero when AC DRIVE is
Vdc 1 Displays the voltage of the
W 0.1 Displays the AC DRIVE output power.
K
WH 0.1 Displays the energy consumed by the system in kWH.
K
MWH 1 Displays the energy consumed by the system in MWH.
o
C 1 Actual heat sink temperature is displayed.
% 0.1 The torque current value is displayed using the motor rated current as
100% .
% 0.1 The excitation current value is displayed using the motor rated current as
100%.
o
F 1 Actual heat sink temperature is displayed in degree F.
Description
OFF
reference in the unit selected
PID
feedback in the unit selected
PID
.
OFF
bus in the main circuit.
DC
, it will display
