No. Parameter
C614 PID Display Unit
Selection
6
C615 Sleep Mode
Selection
C616 Sleep Mode Enter
Frequency
C617 Sleep Mode Active
Delay
C618 Sleep Mode Wake
Up Band
C619 Sleep Mode Leave
Condition
Amtech
6-22
Unit Def Min Max
1 0 69
0 0 1
Hz 0.10 0.00 600.00
Sec 0 0 999
% 5.0 0.0 100.0
1 1 2
Res Description
1 Select the unit for the PID signal.
=0: No Unit =1: %
2
=3: kg/cm =4: ºC
=6: CFM =7: m
=9: Amp =10: kW
=12: Hz =13: s
=15: rpm =16: kh
=18: mA =19: mV
=21: kWh =22: hp
=24: m/s =25: dm
=27: kPa =28: GPM
=30: MGD =31: inHg
=33: kb/s =34: kHz
=36: ppm =37: pps
3
=39: Km /h =40: l/h
3
=42: m /min =43: kg/s
=45: kg/h =46: mbar
=48: GPS =49: gal/s
=51: gal/h =52: ft
3
=54: ft /h =55: lb/s
=57: lb/h =58: FPS
=60: inH O =61: in wg
2
=63: lbsi =64: ms
=66: d =67: inWC
=69: Nm
1 When the sleep mode is selected, the inverter
output is switched OFF, if the frequency
reference (or PID output) remains below the
sleep mode enter frequency for the set time
period. Sleep mode can be used with or without
PID control.
=0: Disable
=1: Enable
0.01 This is the frequency used to activate the sleep
mode and turn off the inverter.
1 The inverter output will be turned off if the
frequency reference (or PID output) remains
below sleep mode enter frequency.
0.1 This is set with respect to the max frequency
and used as hysteresis when leaving the sleep
mode. The inverter will be turned on when the
frequency reference (or PID output) exceeds the
sleep mode enter frequency + wake up band.
1 Define the condition to leave the sleep mode.
=1: Freq Ref > C616 Sleep Mode Enter Freq
=2: Freq Ref > A102 Min Freq
WP
=2: PSI
=5: ºF
3
/h =8: LPM
=11: V
=14: h
=17: lb ft
=20: W
=23: MWh
3
/s =26: bar
=29: ft
=32: FPM
=35: ohm
=38: l/s
3
=41: m /s
=44: kg/m
=47: Pa
=50: gal/m
3 3
/s =53: ft /m
=56: lb/m
=59: ft/s
=62: ft wg
=65: Mrev
=68: m/min
