FUNCTION EXPLANATIONS

GROUP-1
M101: Output Frequency (Hz)
It displays output frequency of AC DRIVE in Hz. When the AC DRIVE is stop, it will display zero.
When auxiliary drive is selected, this parameter displays the output frequency of the auxiliary drive.
When selected for the normal parameter display in A601~A608, the value will be displayed with "Hz"
unit.
M102: Motor Speed (rpm)
It displays the motor / shaft speed in rpm. When the AC DRIVE is stop, it will display zero.
If Motor control mode A401 = 1, 3: It displays calculated motor speed or shaft rpm using Line speed
display setting A104 or D205 (for auxiliary drive) and M101.
If Motor control mode A401 = 2, 4: It displays actual speed of motor shaft using encoder.
When auxiliary drive is selected, this parameter displays the auxiliary motor speed.
When selected for the normal parameter display in A601~A608, the value will be displayed with "rpm"
unit.
6
M103: Output Current (Amp)
It displays actual output current of AC DRIVE in Ampere. When the AC DRIVE is stop, it will display
zero. When auxiliary drive is selected, this parameter displays the output current of the auxiliary drive.
When selected for the normal parameter display in A601~A608, the value will be displayed with
"Amp" unit.
M104: Output Current (%)
It displays actual output current of AC DRIVE as a percentage of rated motor current B103. When
auxiliary drive is selected the rated motor current programmed in D103 is considered.
Output current (%) = Output current (M103) X 100 / Motor current (B103 or D103)
When the AC DRIVE is stop, it will display zero. When selected for the normal parameter display in
A601~A608, the value will be displayed with "%L" unit.
M105: Set Frequency (Hz*)
This parameter displays the set value of frequency in Hz. When local (Digital Operation Panel) option
is selected as frequency reference input in A106, it will display the value of A101 or D201 (for auxiliary
drive). When selected for the normal parameter display in A601~A608, the value will be displayed
with "Hz*" unit.
M106: Frequency Reference Input
It displays currently selected frequency reference input source in A106 or D204 (for auxiliary drive).
M107: Set Torque (%)
This parameter displays the set value of torque in %, when motor control mode A401 = 3,4. If local
(Digital Operation Panel) option is selected as torque reference input, it will display the value of A107.
When selected for the normal parameter display in A601~A608, the value will be displayed with "%*"
unit.
