Amtech Axpert-Eazy Series Instruction Manual page 125

14 Fault Alarm
15 PID Up Limit
16 PID Lo Limit
17 Temp Alarm
18 Ready
19 Pump-1
20 Pump-2
21 Pump-3
22 Pump-4
23 Doff-End Alarm This turns ON only at the point going back the set time (E105) from the
24 Sleep Mode
25 Fault
26 PLC Output 1
27 PLC Output 2
28 PLC Output 3
29 PLC Output 4
30 PLC Output 5
31 PLC Output 6
32 PLC Output 7
33 PID F/B ULmt
34 PID F/B LLmt
35 FAN Control
36 Ready1
37 MBRK
38 KEB ON
39 STO Feedback
40 Panel Temp
Alarm
The default setting of the programmable sequence outputs are as under.
TERMINAL OPTION
PSO1 2
Axpert-Eazy AC Variable Frequency Drive
This output is ON when minor fault alarm is detected.
The output will be activated when the PID output reaches to the
programmed upper limit value.
The output will be activated when the PID output reaches to the
programmed lower limit value.
The output is ON when the heat sink temperature exceeds the set
Temperature Alarm Level in C311
The output is ON when the unit is ready to start. The soft charge
contactor is energized and no fault condition persists.
This is applicable to Multi-pump function only. The output turns ON,
when the respective pump is ON.
moment auto stop occurs after completion of the final step when
performing spinning frame operation.
This turns ON when the unit is in sleep mode.
The output is ON when fault occurs.
Option 26~32 are use to write PSO status from In-built PLC to Inverter.
This is explained in In-built PLC Function explanation.
The output will be activated when the PID feedback reaches to the
programmed upper limit value.
The output will be activated when the PID feedback reaches to the
programmed lower limit value.
The output is ON when the heat sink temperature exceeds the set
temperature level in C315.
The output is OFF when the heatsink temperature goes below the set
level in C315 minus the set hysteresis level in C316.
Once the output is ON then remains ON for 10 minute even if the above
condition is satisfied or not.
This option is for common dc application. Ready1 will be on 3 seconds
after soft charge operation. This will make sure that the capacitors are
charged to the fullest level. The PSI37: Ready1 feedback will be required
in this case. It will turn off and turn on the Ready1 PSO at every 3
seconds, If the feedback is not available.
Outputs an external brake command.
The output will be on when the KEB function is activated.
The output will be on when STO function is activated (Hard link is not
connected if this function is selected in any PSI).
This output will be on if the panel inside temperature > C324 - 5. Output
will be off if panel inside temperature < C324 – 7.
