MODE-G: Pattern Run Function Parameters
No. Parameter
GROUP-1: MODE SELECTION FOR PATTERN RUN TABLE-1
G101 PR Mode T1-STP1
G102 PR Mode T1-STP2
G103 PR Mode T1-STP3
G104 PR Mode T1-STP4
G105 PR Mode T1-STP5
G106 PR Mode T1-STP6
G107 PR Mode T1-STP7
G108 PR Mode T1-STP8
G109 PR Mode T1-STP9
G110 PR Mode T1-
STP10
G111 PR Mode T1-
STP11
G112 PR Mode T1-
STP12
6
G113 PR Mode T1-
STP13
G114 PR Mode T1-
STP14
G115 PR Mode T1-
STP15
GROUP-2: MODE SELECTION FOR PATTERN RUN TABLE-2
G201 PR Mode T2-STP1
G202 PR Mode T2-STP2
G203 PR Mode T2-STP3
G204 PR Mode T2-STP4
G205 PR Mode T2-STP5
G206 PR Mode T2-STP6
G207 PR Mode T2-STP7
G208 PR Mode T2-STP8
G209 PR Mode T2-STP9
G210 PR Mode T2-
STP10
G211 PR Mode T2-
STP11
G212 PR Mode T2-
STP12
G213 PR Mode T2-
STP13
G214 PR Mode T2-
STP14
G215 PR Mode T2-
STP15
Amtech
6-30
Unit Def Min Max
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
1 1 3
Res Description
1 Select the required mode for pattern run
function for each step of Table-1
1
1 =1: STOP
1 =2: FORWARD
1 =3: REVERSE
1
1
1
1
1
1
1
1
1
1
1 Select the required mode for pattern run
function for each step of Table-2
1
1 =1: STOP
1 =2: FORWARD
1 =3: REVERSE
1
1
1
1
1
1
1
1
1
1
