Amtech Axpert-Eazy Series Instruction Manual page 63

MODE-C Parameters
No. Parameter
GROUP-1: PROGRAMMABLE INPUT/OUTPUT
C101 PSI-1
C102 PSI-2
C103 PSI-3
C104 PSI-4
C105 PSI-5
C106 PSI-6
C107 PSO-1
C108 PSO-2
C109 PSO-3
C110 PSO-4
C111 Programmable
Relay1
C112 Programmable
Relay2
C113 Programmable
Fault Relay
C114 PSI-RUN
C115 PSI-STOP
GROUP-2: ANALOG OUTPUT SELECTION
C201 Vout-1
C202 Vout-2
C203 Iout-1
C204 Iout-2
C205 Vout-1 Gain
Axpert-Eazy AC Variable Frequency Drive
Unit Def Min Max
2 1 42
10 1 42
11 1 42
4 1 42
5 1 42
6 1 42
2 1 40
6 1 40
1 1 40
1 1 40
2 1 40
1 1 40
25 1 40
24 1 42
25 1 42
1 1 15
2 1 15
3 1 15
4 1 15
1.000 0.100 2.500
Res Description
1 The different options are as under.
1 =1: Not Used
=3: Ramp Select
1
=5: Preset i/p-1
1
=7: Freq Increase
=9: Aux Drive
1
=11: Fault Reset
1
=13: Reverse
=15: Ref Select 0
=17: PR Step Skip
=19: PR/RSF Reset
=21: PID Disable
=23: Ext Fault-NC
=25: Stop
=27: Drive Enable-NC
=29: PLC input 2
=31: PLC input 4
=33: PLC input 6
=35: PLC input 8
=37: Ready1 F/B
=39: Reverse Run
=41: Reverse Jog
1 The different options are as under.
1 =1: Not Used
=3: Local
1
=5: I-Detection
1
=7: Speed Detect1
=9: Acceleration
1
=11: Aux Drive
=13: Zero Speed
1
=15: PID Up Limit
=17: Temp Alarm
=19: Pump-1
1
=21: Pump-3
=23: Doff-End Alarm
=25: Fault
=27: PLC Output 2
=29: PLC Output 4
=31: PLC Output 6
=33: PID F/B ULmt
=35: FAN Control
=37: MBRK
=39: STO Feedback
1 The different options are same as PSI option.
1
1 This configures the function of analog output.
1 =1: Output Frequency
=3: Output Power
1
=5: DC Bus Volt
1
=7: Heat sink Temp
=9: PLC A-O/P 2
=11: PLC A-O/P 4
=13: Excitation
Current
=15: Bi Trq Cur
0.001 This is gain setting for the VO1 analog output.
WP
=2: Jog Select
=4: Preset i/p-0
=6: Preset i/p-2
=8: Freq Decrease
=10: Emergncy Stop-NO
=12: Ext Fault-NO
=14: Terminal
=16: Ref Select 1
=18: PR Step Hold
=20: PID Bypass
=22: Emergncy Stop-NC
=24: Run
=26: Drive Enbl-NO/STO
=28: PLC input 1
=30: PLC input 3
=32: PLC input 5
=34: PLC input 7
=36: Torque Mode
=38: Forward Run
=40: Forward Jog
=42: MBRK Answer
=2: Run
=4: Reverse Run
=6: Freq Attain
=8: Speed Detect2
=10: Deceleration
=12: Timer Output
=14: Fault Alarm
=16: PID Lo Limit
=18: Ready
=20: Pump-2
=22: Pump-4
=24: Sleep Mode
=26: PLC Output 1
=28: PLC Output 3
=30: PLC Output 5
=32: PLC Output 7
=34: PID F/B LLmt
=36: Ready1
=38: KEB ON
=40: Panel Temp Alarm
=2: Output Current
=4: Output Voltage
=6: PID Output
=8: PLC A-O/P 1
=10: PLC A-O/P 3
=12: Uni Trq Cur
=14: Set Frequency
6-17
6
