Amtech Axpert-Eazy Series Instruction Manual page 59

No. Parameter
B314 Unbalance Level
(Output current)
B315 Copy Parameter
Set
B316 Paste Parameter
Set
B317 DC Bus Voltage
Control Gain
B318 KEB Selection
B319 KEB Threshold
Level
B320 KEB Kp
B321 KEB Ti
B322 KEB Td
B323 Voltage Reduction
Time
B324 Voltage Lower
Limit Setting Value
GROUP-4: PRESET SPEED
B401 Preset Speed-1
B402 Preset Speed-2
B403 Preset Speed-3
B404 Preset Speed-4
B405 Preset Speed-5
B406 Preset Speed-6
B407 Preset Speed-7
GROUP-5: SKIP FREQUENCY
B501 Skip Frequency-1
B502 Skip Frequency-2
B503 Skip Frequency-3
B504 Skip Band
Axpert-Eazy AC Variable Frequency Drive
Unit Def Min Max
% 30 0 100
0 0 5
0 0 5
2 2 20
0 0 1
% 80 65 115
1.00 0.01 25.00
mS 500.0 1.0 5000.0
mS 0.5 0.0 500.0
Sec 10.0 0.1 30.0
% 100.0 50.0 100.0
Hz 10.00 0.00 600.00
Hz 15.00 0.00 600.00
Hz 20.00 0.00 600.00
Hz 25.00 0.00 600.00
Hz 30.00 0.00 600.00
Hz 40.00 0.00 600.00
Hz 50.00 0.00 600.00
Hz 0.10 0.00 600.00
Hz 0.10 0.00 600.00
Hz 0.10 0.00 600.00
Hz 0.00 0.00 10.00
Res. Description
1 Set the unbalance current level for the output.
When the current unbalance exceeds the set
level, the unit will trip. Set to 0% to disable the
function.
1 Copy all parameters from control side to the
Display EEPROM. User can copy 5 sets of all
parameters.
=0:Ent Copy Set
=1:Copy Set 1
=2:Copy Set 2
=3:Copy Set 3
1 Paste all parameters from Display EEPROM to
the control side. User can paste 5 sets of all
parameters.
=0:Ent Paste Set
=1: Paste Set 1
=2: Paste Set 2
=3: Paste Set 3
1 This is gain setting for DC Bus voltage control
(B307 = 2: Frequency Increase).
1 This parameter will select the KEB function.
0:Disable;1:Enable
1 Threshold level for KEB function.
0.01 This parameter is used to set the proportional
gain of KEB PID controller.
0.1 This parameter is used to set the integral time
constant of KEB PID controller.
0.1 This parameter is used to set the derivative time
constant of KEB PID controller.
0.1 Set the time for the output voltage to drop from
the V/f setting value to 0V for high-efficiency
operation function.
0.1 When selecting a high-efficiency operation
function, set 50 to 99.
0.01 These preset speeds can be selected by
programmable sequence inputs and one can set
0.01
the frequencies as per requirement.
0.01
0.01
0.01
0.01
0.01
0.01 Sets the skip frequencies and the avoidance
band for the each frequency.
0.01
0.01
0.01
WP
=4:Copy Set 4
=5:Copy Set 5
=4: Paste Set 4
=5: Paste Set 5
6-13
6
