Amtech Axpert-Eazy Series Instruction Manual page 56

MODE-B Parameters
No. Parameter
GROUP-1: MOTOR PARAMETERS
B101 Rated Input
Voltage
B102 Motor Voltage
B103 Motor Current
6
B104 Motor Frequency
B105 Motor Speed
B106 Motor Output
Rating
B107 Motor Poles
B108 No Load Output
Voltage
B109 Encoder Pulses
B110 Carrier Frequency
B111 DTC Gain
B112 kW without VFD
B113 Currency Selection
B114 Energy Cost
B115 Local Set Voltage
B116 Output Voltage
Reference
Selection
Amtech
6-10
Unit Def Min Max
Vac 3 1 5
8 6 8
11 9 11
14 12 15
Vac 415 380 480
575 500 575
690 600 690
230 200 240
Amp M304 0.3* M304
M304
Hz 50.0 10.0 600.0
rpm 1500 1 36000
kW M305 0.1 1500.0
4 2 16
Vac 160 20 480
P/R 1024 60 10000
kHz 5 2 10
4 6
70 0 255
kW M305 0 65535
1 1 3
4.000 0.000 65.535
% 100.0 5.0 100.0
1 1 3
Res. Description
1 Select suitable rated input voltage from the
below selections for 400V, 500V, 600V & 200V
Series.
=1: 380V =2: 400V
=4: 440V =5: 460V
=6: 500V =7: 550V
=9: 600V =10: 660V
=12: 200V =13: 220V
=15: 240V
1 This is the Motor rated Voltage. Set the voltage
mentioned on the motor nameplate. The setting
value depends on the 400V, 500V, 600V or
200V Series model.
0.1 Set the motor rated current from the motor
nameplate. It can be set to 30% of the AC
DRIVE rated current M304
0.1 Set the motor rated frequency from the motor
nameplate.
1 Set the motor rated RPM from the motor
nameplate.
0.1 The motor's rated output at base speed is set.
2 Insert the motor poles.
1 The terminal voltage at no load at the base
speed is set.
1 Set as per the encoder specification.
1 This parameter sets the AC DRIVE carrier
frequency.
For 315kW and higher models in 400V series
and for all models of 500V/600V series.
1 This is gain for the dead time compensation.
Adjust incase of motor hunting.
1 Enter previous kW consumption without VFD.
This parameter is used to calculate the energy
saving using VFD.
1 Select your currency for the energy cost.
=1: INR
=2: USD
=3: EURO
0.001 Enter here the cost per kW in selected currency.
0.1 This is the set voltage when the inverter is used
as variable voltage source application and
voltage reference in B116 is selected as Local.
Set as % of motor voltage B103.
1 Select the set reference for the output voltage,
when inverter is used as variable voltage source
application.
=1: Local
=2: FSV 0-10V
=3: FSI 4-20mA
WP
=3: 415V
=8: 575V
=11: 690V
=14: 230V
