Amtech Axpert-Eazy Series Instruction Manual page 65

No. Parameter Unit
C307 Output Phase
Loss selection
C308 Timer Output
control Selection
C309 Timer output Off Sec
Delay time
C310 Temperature
Control selection
C311 Temperature
Alarm Level
C312 In-built PLC
Selection
C313 Static Pot Options
C314 I-Detection
Hysteresis Level
C315 Fan ON
Temperature Level
C316 Fan OFF
Hysteresis Level
C317 External Brake
Selection
C318 Brake Release Sec
Wait Time
C319 Acceleration Start Sec
Wait Time
C320 Brake Engage Sec
Wait Time
C321 Run Error Sec
Judgment Time At
Engaging Brake
C322 Brake Answer Sec
Error Judgment
Time
Axpert-Eazy AC Variable Frequency Drive
Def Min Max
1 0 1
0 0 1
60 0 3000
1 0 1
o
C 82 0 95
0 0 1
1 1 5
% 5 1 20
o
C 60 50 65
o
C 10 10 30
0 0 1
0.00 0.00 2.50
0.00 0.00 2.50
0.00 0.00 2.50
0.0 0.0 25.0
0.0 0.0 25.0
Res Description
1 Output open-phase is detected if one phase
current is <5% and other two phase currents are
>70% of motor rated current for five cycles,
when this protection is enabled.
=0: Disable
=1: Enable
1 Set the ON/OFF control for the timer output.
=0: ON only when AC DRIVE is ON
=1: ON whenever power is ON
1 Set the time in seconds to delay turning OFF
the timer output after the AC DRIVE OFF
command is received.
1 This parameter controls the automatic change
of the carrier frequency in case of temperature
rise above the predefined level.
1 This is temperature alarm level set point.
Whenever the heat sink temperature exceeds
the set value, the Temp Alarm output will be set.
Hysteresis of 2° C hysteresis will occur with
temperature alarm.
1 By Using this parameter In-built PLC function
can Enable or Disable.
1 This parameter provides selection of the static
pot speed at power up.
=1: Last speed
=2: Min frequency (A102)
=3: Max frequency (A103)
=4: A101 Set frequency
=5: B401 Preset speed-1
1 This parameter sets the hysteresis level for I-
Detection operation
1 Set the temperature level to activate the PSO
for FAN control.
1 Set the hysteresis level to de-activate the PSO
for FAN control.
1 Select external brake function.
=0: Disable =1: Enable
0.01 Set the wait time from the RUN command to the
brake release command.
0.01 Set the wait time from the point the brakes are
released until the motor accelerates. If there is a
brake answer (MBRK Ans), set from answer,
and if none, set time from command.
0.01 Set the wait time (cumulative) from the point the
frequency (speed) command value reaches the
zero speed setting or below until the brake is
engaged.
0.1 A fault stoppage occurs if ON for the RUN
setting time or longer when engaging the brake.
Error judgment is turned OFF at 0.00.
0.1 The brake command and brake answer do not
match for the set time or longer, and a fault
stoppage occurs.
Error judgment is turned OFF at 0.00.
WP
6
6-19
