Amtech Axpert-Eazy Series Instruction Manual page 54

No. Parameter
A501 Manual Torque
Boost setting
A502 Automatic Torque
Boost Selection
A503 Slip Compensation
GROUP-6: PARAMETER SELECTION FOR NORMAL DISPLAY SCREEN
A601 Norm Parameter
A602 Norm Parameter
A603 Norm Parameter
A604 Norm Parameter
A605 Norm Parameter
A606 Norm Parameter
6
A607 Norm Parameter
A608 Norm Parameter
GROUP-7: FREQ REFERENCE MATH OPERATIONS
A701 Multiplier-A106
A702 Math Reference
Input2
A703 Multiplier-A702
A704 Math Operator
A705 Fix Bias
Amtech
6-8
Unit Def Min
% Inv. 0.0
rating
0 0
Hz 0.0 0.0
2.0
1 1
1
5 1
2
3 1
3
4 1
4
8 1
5
11 1
6
12 1
7
15 1
8
1.000 - 10.000
10.000
1 1
1.000 - 10.000
10.000
1 1
Hz 0.00 0.00 600.00
Max Res.
20.0 0.1 When setting manually, set the boost voltage at
0Hz as a percentage in respect to the rated
output voltage. When programmed to zero, it
will be disabled. This is automatically adjusted
by the automatic tuning.
1 1 When automatic torque boost is selected, the
R1 drop compensation and slip compensation
functions will be valid.
=0: Disable
=1: Enable
5.0 0.1 Set the motor's rated slip.
This default value is applicable for V/F Closed
loop control mode only.
25 1 Select from this to display on normal screen.
25 1 =1: M101 Hz
=4: M104 %L
25 1
=7: M110 Fb
25 1
25 1 =10: M203 Vo
25 1 =13: M206 kWh
25 1 =16: M211 ºF
25 1 =19: M116 Amp
Vph
=22: M209 %Tq
25: M219 ACR
O/P
0.001 This is a multiplier to the frequency reference
selected in A106.
9 1 Select the second reference for the math
operations.
=1: Not Used
=3: FSI 4-20mA
=5: IIN 4-20mA
=7: PLC A-O/P 2
=9: PLC A-O/P 4
0.001 This is a multiplier to the math reference input2
selected in A702.
3 1 Select the mathematical operation to be carried
out between frequency reference selected in
A106 and math reference input2 selected in
A702.
=1: + Add
=2: x Multiply
=3: / Divide
0.01 This is fixed bias added into the output after the
math operation.
Description
=2: M102 rpm =3: M103 Amp
=5: M105 Hz* =6: M109 PR
=8: M201 Vry =9: M202 Vyb
=11: M204 Vdc =12: M205 kW
=14: M207 MWh =15: M208 ºC
=17:M217 Enc =18: M115 Amp
Cnt Uph
=20: M117 Amp Tq*
=21: M107
Wph
=23: M210 %Ex 24: M218 ASR
O/P
=2: FSV 0-10V
=4: VIN 0-10V
=6: PLC A-O/P 1
=8: PLC A-O/P 3
WP
