Amtech Axpert-Eazy Series Instruction Manual page 64

No. Parameter
C206 Vout-2 Gain
C207 Iout-1 Gain
C208 Iout-1 Bias
C209 Iout-2 Gain
C210 Iout-2 Bias
C211 FSV Gain
C212 FSV Bias
C213 FSI Gain
C214 FSI Bias
C215 VIN Gain
C216 VIN Bias
C217 IIN Gain
C218 IIN Bias
C219 FSV/FSI Time
Constant
C220 VIN/IIN Time
6
Constant
C221 Vout-1 Bias
C222 Vout-2 Bias
C223 Input voltage gain
GROUP-3: STATUS OUTPUT DETECTION LEVEL
C301 Frequency
Attainment
Detection Width
C302 I-Detection Level
(current detection)
C303 Speed Detection
Level-1
C304 Speed Detection
Level-2
C305 Zero Speed
Detection Level
C306 4-20mA Reference
Loss
Amtech
6-18
Unit Def Min Max
1.000 0.100 2.500
1.000 0.100 2.500
1000 100 1500
1.000 0.100 2.500
1000 100 1500
1.000 0.100 1.500
100 0 1000
1.000 0.100 1.500
1000 0 1500
1.000 0.100 1.500
100 0 1000
1.000 0.100 1.500
1000 0 1500
mS 100 0 1000
mS 100 0 1000
100 0 1000
100 0 1000
1.000 0.100 2.000
% 1.0 0.0 20.0
% 100.0 5.0 200.0
% 95.0 1.0 105.0
% 50.0 1.0 105.0
% 1.0 0.0 50.0
2 1 7
Res Description
0.001 This is gain setting for the VO2 analog output.
0.001 This is gain setting for the IO1 analog output.
1 This is bias setting for the IO1 analog output.
0.001 This is gain setting for the IO2 analog output.
1 This is bias setting for the IO2 analog output.
0.001 This is gain setting for the FSV analog input.
1 This is bias setting for the FSV analog input.
0.001 This is gain setting for the FSI analog input.
1 This is bias setting for the FSI analog input.
0.001 This is gain setting for the VIN analog input.
1 This is bias setting for the VIN analog input.
0.001 This is gain setting for the IIN analog input.
1 This is bias setting for the IIN analog input.
1 This parameter set the filter time constant for
the FSV and FSI analog inputs.
1 This parameter set the filter time constant for
the VIN and IIN analog inputs.
1 This is bias setting for analog output voltage
VO1.
1 This is bias setting for analog output voltage
VO2.
0.001 This parameter sets the gain for VRY (M201)
and VYB (M202) monitor.
The attained frequency output (Freq Attain)
0.1
operation width is set.
The current detection (I-Detection) operation
0.1
level is set. Set with a percentage of the rated
current (B103). The hysteresis will occur with
set value in parameter C314 for the I-Detection
operation.
0.1 The speed detection operation level is set. Set
with a percentage to the max frequency A103.
The output frequency or the motor speed will be
0.1
the comparison target. A 1% hysteresis will
occur with speed detection operation.
0.1 The Zero speed detection operation level is set.
Set with a percentage to the max frequency
(A103). The output frequency or the motor
speed will be the comparison target. A 1%
hysteresis will occur with zero speed operation.
1 This parameter configures the AC DRIVE's
response to a failure of 4-20mA Frequency
reference input signal.
=1: No action at fault detection
=2: Minor fault alarm & run at minimum speed
=3: Minor fault alarm & run at maximum speed
=4: Minor fault alarm & run at set speed
=5: Minor fault alarm & run at preset speed-1
=6: Fault, ramp down to stop
=7: Fault, coast to stop
WP
