Amtech Axpert-Eazy Series Instruction Manual page 57

No. Parameter
B117 Encoder Polarity
B118 No Load Output Amp
Current
B119 Motor Overload
Selection
GROUP-2: MOTOR CONSTANTS
B201 Automatic Tuning
Selection
B202 R1: Primary-Stator
Resistance
Mantissa)
B203 R1: Primary-Stator
Resistance
(Exponent)
B204 R2': Secondary-
Rotor Resistance
(Mantissa)
B205 R2': Secondary-
Rotor Resistance
(Exponent)
B206 L: Leakage
Inductance
(Mantissa)
B207 L: Leakage
Inductance
(Exponent)
B208 M': Excitation
Inductance
(Mantissa)
B209 M': Excitation
Inductance
(Exponent)
B210 Rm: Iron Loss
Resistance
(Mantissa)
B211 Rm: Iron Loss
Resistance
(Exponent)
GROUP-3: PROTECTION PARAMETERS
B301 Stall Current Limit
Axpert-Eazy AC Variable Frequency Drive
Unit Def Min Max
0 0 1
0.3* 1.0 M304
M304
3 1 5
1 1 5
m Inv 0.100 9.999
rating
Inv -3 4
rating
m 1.000 0.100 9.999
0 -3 4
mH 1.000 0.100 9.999
0 -3 4
mH 1.000 0.100 9.999
0 -3 4
m 1.000 0.100 9.999
0 -3 5
% 125.0 0.0 200.0
Res. Description
1 This is used to select Encoder polarity.
=0:Forward
=1:Reverse
0.1 Set the motor no load current.
1 =1: 120% for 60 Sec
=2: 150% for 60 Sec
=3: 150% for 120 Sec
=4: 150% for 180 Sec
=5: 150% for 240 Sec
1 The Automatic tuning mode is selected.
=1: Disable Auto-tuning
=2: Stationary (Belt ON) (For V/F control)
=3: Rotational (Belt OFF) (For Vector
control)
=4: Extended Rotational (Belt OFF) (For
Vector control)
=5: Reserved
0.001 The motor circuit constant is set.
This combination means below.
B202 = 1.000, B203 = 0
R1 = 1.000 (B202) x (10)
1
= 1.000 [m ]
0.001 This is mantissa section of the entered value for
Secondary (Rotor) Resistance of motor.
1 This is exponent section of the entered value for
Secondary (Rotor) Resistance of motor.
0.001 This is mantissa section of the entered value for
Leakage Inductance of motor.
1 This is exponent section of the entered value for
Leakage Inductance of motor.
0.001 This is mantissa section of the entered value for
Excitation Inductance.
1 This is exponent section of the entered value for
Excitation Inductance.
0.001 This is mantissa section of the entered value for
Iron Loss Resistance.
1 This is exponent section of the entered value for
Iron Loss Resistance.
0.1 Set the current value as a percentage of motor
rated current for normal running condition. The
default value is 125% for normal duty and 155%
for heavy duty mode.
WP
0 (B203)
[m ]
6-11
6
