8. Analog Input From In-built PLC to Inverter:
The signals from In-built PLC can be given as Analog Input.
Parameters A106, A108, A702, D204, C603 & C604 have four PLC A-O/P options.
User has to select one of these options for this operation. Use WRITE_AN_O/P (054) command
in PLC program for this operation.
9. Analog Output From In-built PLC to Inverter:
Analog output can be given from In-built PLC.
Parameters C201 to C204 have four PLC A-O/P options. User has to select one of these options
for this operation. Use WRITE_AN_O/P (054) command in PLC program.
10. Analog Input From Inverter to In-built PLC:
The Inverter's Analog input signals (FSV, FSI, Iin, Vin) can be read to In-built PLC. These Inputs
are stored in Register No. 94 to 97.
11. Analog Output From Inverter to In-built PLC
The Inverter's Analog output signal (C201 to C204's 1 to 7 option) can be read to the In-built PLC.
These outputs are stored in Register No. 86 to 93.
12. In-built PLC PANEL Parameter (C701 to C712): Parameter
Twelve parameters can be input. Related memory location from 101 to 112.
Note: To get proper output from PLC program, make sure to select correct option in PLC parameters state
above. It is advisable to set unused PLC parameters to default conditions.
Memory Description:
There are 115 numbers of 16-bit register or memory locations, 100 numbers of 1-bit flag and one 32-
bit register.
16-bit register description has shown below table.
16-bit
Register Name
No.
0-75 User Memory
76 User Memory
77 User Memory
78 User Memory
79 User Memory
80 User Memory
81 User Memory
82 User Memory
83 User Memory
84 User Memory
85 User Memory
86 Output Voltage
87 Output Current
88 Output Power
89 Output Frequency
90 DC Bus Voltage
91 PID output
92 Torque Current
93 Heat sink temperature
Axpert-Eazy AC Variable Frequency Drive
Access Type
Read/Write User can Read and Write
Read/Write User can Read and Write
Read/Write User can Read and Write
Read/Write User can Read and Write
Read/Write User can Read and Write
Read/Write User can Read and Write
Read/Write User can Read and Write
Read/Write User can Read and Write
Read/Write User can Read and Write
Read/Write User can Read and Write
Read/Write User can Read and Write
Read Read Output Voltage value
Read Read Output Current value
Read Read Output Power value
Read Read Output Frequency value
Read Read DC Bus Voltage value
Read Read PID output value
Read Read Torque Current value
Read Heat sink temperature
Read value
In-built PLC
Details
-32768 to 32767
M313 – M322
(during power on
condition) or
-32768 to 32767
100d = 100%
6
Value
M203
M104
M205
M101
M204
M209
M211
6-111
