7 Voltage Limit
8 Speed Search
9 PLCT Active
10 Sleep Mode
11 KEB ON
12 Normal Run
13 Acceleration
3
14 Deceleration
15 Auto Tuning
16 DC Braking
17 Drive Stop
18 Torque Mode
19 Mains On
When first time MODE key is pressed, lastly accessed parameter of lastly accessed group of Mode-M
will appear with its data. Below figure shows the parameter M101 of Group-1 of Mode-M.
Mode-M
M o d e - M
M 1 0 1
F w d , L c l , D r i v e
Parameter Data
Parameter Number and Name
The first line indicates the present mode and group. The second line indicates the parameter number
with its name and the third line shows its value. The fourth line shows the present status and remains
all the time except fault condition, contact information and fault history.
3-2 Modes & parameters
The parameters are grouped into Modes and Groups according to their functions.
The configuration of the parameters is as under.
Amtech
3.4
It shows that the dc bus voltage control function is active.
It shows that the speed search operation is in progress.
It shows that the Power-Loss-Carry-Through function is in progress.
It shows that the AC Drive is in sleep mode.
It shows that the KEB function is active.
It shows that ramp up / down action is over and unit is running in normal
condition.
It shows that the unit is accelerating to the set speed.
It shows that the unit is decelerating.
It shows that the auto tuning function is activated and the process is on.
It shows that the dc braking is active.
It shows that the AC Drive is in stop condition.
It shows that the AC Drive is in Torque mode.
It shows that the mains power supply is ON.
O u t p u t
0 . 0 0
Group-1
G r o u p - 1
F r e q
H z
S t o p
