Amtech Axpert-Eazy Series Instruction Manual page 72

MODE-E: Ring Spinning Frame (RSF) Function Parameters
No. Parameter
GROUP-1: RSF / PATTERN RUN PARAMETER SELECTION
E101 RSF/ Pattern Run
Selection
E102 Table-1 Step
Selection
E103 Table-2 Step
Selection
E104 Table-3 Step
Selection
E105 Doff End Alarm
Time
E106 Hank Count Gain
E107 Hank Gain
Multiplier
6 E108 Table Selection
GROUP-2: RSF FREQUENCY FOR TABLE-1
E201 Freq T1-STP1
E202 Freq T1-STP2
E203 Freq T1-STP3
E204 Freq T1-STP4
E205 Freq T1-STP5
E206 Freq T1-STP6
E207 Freq T1-STP7
E208 Freq T1-STP8
E209 Freq T1-STP9
E210 Freq T1-STP10
E211 Freq T1-STP11
E212 Freq T1-STP12
E213 Freq T1-STP13
E214 Freq T1-STP14
E215 Freq T1-STP15
GROUP-3: RSF TIME FOR TABLE-1
E301 RSF Time T1-
STP1
E302 RSF Time T1-
STP2
E303 RSF Time T1-
STP3
E304 RSF Time T1-
STP4
Amtech
6-26
Unit Def Min Max
1 1 3
15 1 15
15 1 15
15 1 15
Sec 1 0.1 3000
1.000 0.001 30.000
2 1 3
1 1 3
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Hz 5.00 0.01 600
Sec 10.0 0.1 6000.0
Sec 10.0 0.1 6000.0
Sec 10.0 0.1 6000.0
Sec 10.0 0.1 6000.0
Res Description
1 =1: Disable
=2: RSF Function
=3: Pattern Run Function
1 Select the number of steps for table-1 for RSF.
1 Select the number of steps for table-2 for RSF.
1 Select the number of steps for table-3 for RSF.
0.1 Outputs an alarm signal for the set time from
completion of the final step until directly before
stoppage.
0.001 This is hank count calculation gain used to
display the hank count.
1 =1: X0.1
=2: X1.0
=3: X10
1 Select the required table for RSF / Pattern Run
function.
0.01 Set frequency for Table-1, Step-1.
0.01 Set frequency for Table-1, Step-2.
0.01 Set frequency for Table-1, Step-3.
0.01 Set frequency for Table-1, Step-4.
0.01 Set frequency for Table-1, Step-5.
0.01 Set frequency for Table-1, Step-6.
0.01 Set frequency for Table-1, Step-7.
0.01 Set frequency for Table-1, Step-8.
0.01 Set frequency for Table-1, Step-9.
0.01 Set frequency for Table-1, Step-10.
0.01 Set frequency for Table-1, Step-11.
0.01 Set frequency for Table-1, Step-12.
0.01 Set frequency for Table-1, Step-13.
0.01 Set frequency for Table-1, Step-14.
0.01 Set frequency for Table-1, Step-15.
0.1 Set time for Table-1, Step-1 for RSF function.
0.1 Set time for Table-1, Step-2 for RSF function.
0.1 Set time for Table-1, Step-3 for RSF function.
0.1 Set time for Table-1, Step-4 for RSF function.
WP
