Amtech Axpert-Eazy Series Instruction Manual page 58

No. Parameter
B302 Adjustable Over
Current Level
B303 Acceleration
Current Limit
B304 Under Current
Level
B305 Overload Setting
B306 Earth Fault
detection Level
B307 DC Bus Voltage
Control
B308 Reverse Direction
Lock
6
B309 Change Password
B310 Parameter Lock
B311 Default Value Load
Note: The value entered in this parameter will not be memorized. It correct value is entered, appropriate action will be taken
and "00" will be displayed. If incorrect value is entered, no action will be taken and "00" will be displayed.
B312 0Hz Overload
Setting
B313 0.7*BF Overload
Setting
Amtech
6-12
Unit Def Min Max
% 300 50 300
% 150 50 200
% 0 0 90
% 105 50 105
100 50 100
% 50 0 100
1 1 3
0 0 1
0 0 9999
0 0 9999
0 0 111
222
333
444
555
666
777
% 105 0 B313
% 105 0 B305
Res. Description
1 Set the upper current level as a percentage of
motor rated current. When set to 300%, this
feature is disabled.
1 Set the upper current limit as a percentage of
motor rated current for Acceleration.
1 Set the lower current level as a percentage of
motor rated current for running condition.
1 This is reference for timed overload
characteristic. The inverse time characteristics
will change with change in B305.
This overload setting for Heavy Duty.
This overload setting for Normal Duty.
1 This parameter sets the earth fault detection
level.
1 When enabled, it will prevent the overvoltage
during RUN condition.
=1: Disable
=2: Frequency Increase
=3: Stop Deceleration
1 Set this to prevent unintentional reverse
direction operation. When enabled, ensure that
forward direction is selected in A305 (or at
terminal). The AC DRIVE will not start
otherwise.
=0: Disable
=1: Enable
1 User can change the 4-digit user password for
parameter lock.
1 User selectable 4-digit password to prevent
unintentional parameter changes from the digital
operation panel.
1 The current active parameters will be saved to
non-volatile memory.
The saved parameters will be fetched from
memory and now the drive will respond to these
parameters.
All default values will be loaded excluding C205
to C218 and B202 to B211 as per 60Hz/460V
(US standard).
All default values will be loaded excluding C205
to C218 and B202 to B211 as per 50Hz/415V.
When set to 555, the fault history buffer is
cleared. No previous fault codes and related
parameters will be available.
All the user parameters will be set to default
including C205 to C218 and B202 to B211 as
per 50Hz/415V.
All the PLC parameters will be set to default.
1 For the self-cooling type motor, when operating
at low speed, set these parameters to meet the
motor characteristics.
1
WP
