Amtech Axpert-Eazy Series Instruction Manual page 161

Sr. Command Op-
No. Name Code
56 DISPLAY_FLG 062 X1 (0-7)
57 LPF1 063 Register (n) Register
58 LPF2 064 Register (n) Register
59 LPF3 065 Register (n) Register
60 LPF4 066 Register (n) Register
61 JMPC 067 X (1-100)
62 JMPNC 068 X (1-100)
Range of n, n1, n2 and m are 0 to 114 for register and 0 to 99 for flag.
•
Register 0 to 85 have Read and Write access. Register 86 to 114 are Read Only.
•
Flag status is single bit locations, which is 0 to 99.
•
Memory Locations for Registers and Flag status are different.
•
X1 indicate Display parameter (M313 to M323)
•
X indicates Command No.
•
Axpert-Eazy AC Variable Frequency Drive
DATA1 DATA2 DATA3
Flag (n) 000
Tc (0-100) Inputs = Register (m) and Tc (in mS)
(m)
Tc (0-100)
(m)
Tc (0-100)
(m)
Tc (0-100)
(m)
Flag (n) 000
Flag (n) 000
Description
It will display value of selected Flag (n) on X1 bit
location.
LPF Output = Register (n)
If Flag (n) = 1, then JUMP to X Command no.
If Flag (n)! = 1, then JUMP to X Command no.
