Digital outputs
Potential Free Contacts
Programmable Analog
Outputs
Network connectivity
Auto Restart
PID Controller
Display and Keypad unit
Protective Function
Smooth Operation
Fault history
Installation location
Vibration
Ambient temperature
Storage temperature
Altitude (above sea level) 1000 m (3300 ft) without derating, above this derate 5% per 305 m (1000 ft)
Humidity
Enclosure
Consult Amtech for the details on models AMT-011-X to AMT-030-X
The input power factor is 0.9 with 3% ACL
The inverter efficiency will be >98%
Note1: Indicates the total effective value including the higher harmonics
Note2: The maximum applicable motor output is given for a standard induction motor.
Note3: If the default carrier frequency is exceeded, derate the output current by 5% per 1 kHz as the reduced rating.
13
A
Amtech
A.4
4-Programmable Sequence Outputs, open collector type
Programmable to 40 different options: Not Used, Run, Local, Reverse Run, I-Detection, Freq Attain, Speed
Detect1, Speed Detect2, Acceleration, Deceleration, Aux Drive, Timer Output, Zero Speed, Fault Alarm, PID
Up Limit, PID Lo Limit, Temp Alarm, Ready, Pump-1, Pump-2, Pump-3, Pump-4, Doff-End Alarm, Sleep
Mode, Fault, PLC Output 1, PLC Output 2, PLC Output 3, PLC Output 4, PLC Output 5, PLC Output 6, PLC
Output 7 PID F/B ULmt, PID F/B LLmt, Fan Control, Ready1, MBRK, KEB ON, STO Feedback and Panel
Temperature Alarm
3-Programmable relays:
2-Programmable analog voltage outputs VO1 & VO2: 0~10 Vdc
2-Programmable analog current outputs IO1 & IO2: 4~20 mA
Programmable between 15 different options: Output Frequency, Output Current, Output Power, Output
Voltage, DC Bus Volt, PID Output, Heat sink temperature, PLC Analog Output 1, PLC Analog Output 2, PLC
Analog Outpu3, PLC Analog Output 4, Unipolar Torque Current, Excite Current, Set Frequency and Bipolar
Torque Current
RS-485 for PC Interface with Modbus-RTU protocol as standard
Adjustable up to 10 times for ten faults
Inbuilt PID can be used as stand alone
Total 80-Character, 4-Line LCD panel with backlit, 8-Key keypad, 3-Status indicating LED for Run, Stop and
Fault.
Simultaneous display of eight selectable monitor parameters from Output frequency, RPM, Current, %
Current, Set frequency, PID Reference, PID Feedback, Input voltage Vry, Input voltage Vyb, Output voltage,
DC Bus voltage, kW, kWH, MWH, Heat sink temperature ° C and ° F, Set Torque, Torque Current, Excitation
Current, ASR O/P Monitor and ACR O/P Monitor
Current Limit, Over current fault, Drive over load fault, Motor over load fault, Load side short circuit fault,
Under current fault, DC Bus Over voltage fault, DC Bus Under voltage fault, Temperature fault, Output phase
loss fault, Earth (Ground) fault, External fault, Charging fault, Current sensor fail fault, EEPROM fault,
4~20mA reference missing fault, Auto tuning fault, Emergency stop, Communication loss, Output unbalance
current fault.
Speed Search, Auto Restart and Power Loss Carry Through functions, Heat sink over temperature alarm,
KEB (kinetic energy buffering)
Last ten faults with status and eight operational parameters like output frequency, output current, dc bus
voltage and heat sink temperature, Input voltage, Total ON Time, kWH, MWH.
Indoor
As per EN 60068-2-6, Acceleration: 1g, Frequency: 10 Hz ~ 150 Hz
0~50° C (32 ~ 122° F), Open chassis module from 400 kW onwards
-20° C (-4° F) ~70° C (158° F)
0~95% maximum non-condensing
IP00
1-NO, 1-NC for 2A @ 240 VAC
Programmable to 40 different options same as digital outputs
