No. Parameter
C323 Static Pot Option
during stop
C324 Panel
Temperature Limit
GROUP-4: SERIAL COMMUNICATION
C401 Baud Rate
C402 Station Number
C403 Parity
C404 Response Time
6
C405 Operation Panel
Communication
Loss Selection
GROUP-5: AUTO RESTART & SPEED SEARCH FUNCTION
C501 No. Of Restart
C502 Restart Wait Time
C503 Emergency Stop
Mode
C504 Speed Search
Selection
C505 Speed Search
Current Limit
C506 Speed Search
Frequency
Deceleration Time
C507 Speed Search
Voltage
Acceleration Time
C508 Speed Search
Wait Time
Amtech
6-20
Unit Def Min Max
1 1 5
60 25 70
bps 4 1 6
1 1 247
1 1 3
Sec 0.01 0.00 2.00
0 0 1
0 0 10
Sec 5 1 30
1 1 3
0 0 1
% 70 30 200
Sec 2.00 0.01 30.00
Sec 2.0 0.1 10.0
Sec 2.0 0.0 20.0
Res Description
1 This parameter provides selection of the static
pot speed at stop.
=1: Last Speed
=2: Min Frequency
=3: Max Frequency
=4: A101 Set Freq
=5: B401 Preset Speed-1
1 This parameter is set limit for panel temperature
fault when IU/DU system is in use.
1 Sets the baud rate for the serial communication.
=1: 1200 bps
=3: 4800 bps
=5: 19200 bps
1 Sets the station number (address).
1 Setting the parity requirement for the
communication
=1: No Parity
=2: Odd parity
=3: Even Parity
0.01 Set the minimum time from receiving the
command to returning an answer.
1 Enable or disable the operation panel
communication loss fault. If enabled, AC DRIVE
will generate fault if it does not receive any
response from the operation panel within
100msec.
=0: Disable
=1: Enable
1 Sets the number of restart for ten faults.
1 Sets the wait time before auto restart.
1 Set the stopping method for the emergency
stop.
=1: Coast to stop without fault output
=2: Coast to stop with fault output
=3: Ramp down to stop
1 Enable or disable the speed Search operation.
=0: Disable
=1: Enable
1 Sets the speed search operation current as a
percentage, taking the AC DRIVE rated current
as 100%. Not usually necessary to set. When
restarting is not possible with the factory
settings, reduce the value.
0.01 This decides the frequency ramp down time
from max frequency during speed search
operation.
0.1 This decides the output voltage ramp up time
from zero to base voltage during speed search
operation.
0.1 The wait time after the output is cut off to when
the speed search operation is started is set. Set
the time to when the motor residual voltage is
abated for this parameter. The search operation
is delayed by the time set here.
WP
=2: 2400 bps
=4: 9600 bps
=6: 38400 bps
