Amtech Axpert-Eazy Series Instruction Manual page 51

WP: Indicates that this parameter is Write Protected during RUN condition.
MODE-A Parameter
No. Parameter
GROUP-1: FREQUENCY SETTING
A101 Local Set
Frequency
A102 Minimum
Frequency
A103 Maximum
Frequency
A104 Jog Frequency
A105 Line Speed Setting
A106 Frequency
Reference Input
A107 Local Set Torque
A108 Torque Reference
Input
A109 Extended
Parameter
A110 Frequency
Reference Select 1
A111 Frequency
Reference Select 2
A112 Frequency
Reference Select 3
A113 Stop Frequency
GROUP-2: ACCELERATION / DECELERATION TIME
A201 Acceleration Time-
1
Axpert-Eazy AC Variable Frequency Drive
Unit Def Min Max
Hz 10.00 0.00 600.00
Hz 0.10 0.00 600.00
Hz 50.00 0.10 600.00
Hz 5.00 0.00 600.00
1500 0 3000
1 1 18
% 0.0 -200.0 200.0
1 1 18
0 0 1
3 1 18
10 1 18
11 1 18
1.00 0.1 600.00 0.01
Sec 10.0 0.1 6000.0
Res. Description
0.01 This is the frequency set from Digital Operation
Panel ( Keypad Module).
LCD
0.01 These two parameters are used to configure
Minimum and Maximum Frequency of the AC
DRIVE.
0.01
0.01 This is frequency setting for jog input.
1 line speed display. The entered value will
RPM
be displayed as motor speed in M102 at 50Hz in
open loop v/f mode. It will not have any effect in
vector control modes.
1 This is used to select the speed reference.
=1: Local
=3: FSI 4-20mA
=5: FSI 0-20mA
=7: FSI 20-4mA
=9: FSI 20-0mA
=11: Serial
=13: VIN 0-10V
=15: PLC A-O/P 1
=17: PLC A-O/P 3
0.1 This is set torque from the operation panel in
vector control mode.
1 This is used to select the torque reference in
vector control mode.
=1: Local
=3: FSI 4-20mA
=5: FSI 0-20mA
=7: FSI 20-4mA
=9: FSI 20-0mA
=11: Serial
=13: VIN 0-10V
=15: PLC A-O/P 1
=17: PLC A-O/P 3
1 This will enable to display mode D, mode E,
mode G, mode H and mode P.
=0: Disable
=1: Enable
1 This is used to select the speed reference using
Ref Select 0 & Ref Select 1 through PSI. Refer
description for selection detail.
1 =1:Local
=3:FSI 4-20mA
=5:FSI 0-20mA
1
=7:FSI 20-4mA
=9:FSI 20-mA
=11:Serial
=13:Vin 0-10V
=15: PLC A-O/P 1
=17: PLC A-O/P 3
During deceleration drive act as coast to stop at
this frequency.
0.1 Time needed to change the output frequency
from zero to maximum.
WP
=2: FSV 0-10V
=4: FSV 0-5V
=6: FSV 10-0V
=8: FSV 5-0V
=10: Static pot
=12: PID Output
=14: IIN 4-20mA
=16: PLC A-O/P 2
=18: PLC A-O/P 4
=2: FSV 0-10V
=4: FSV 0-5V
=6: FSV 10-0V
=8: FSV 5-0V
=10: Static pot
=12: PID Output
=14: IIN 4-20mA
=16: PLC A-O/P 2
=18: PLC A-O/P 4
=2:FSV 0-10V
=4:FSV 0-5V
=6:FSV 10-0V
=8:FSV 5-0V
=10:Static Pot
=12:PID Output
=14:Iin 4-20mA
=16: PLC A-O/P 2
=18: PLC A-O/P 4
6-5
6
