Setting Temperatures / Calibrating Sensors - AGFA d-lab.3 Technical Documentation Manual

Settings
Replenishment rates
Solution
Developer
Bleach-fix
Stabilizer

Setting temperatures / calibrating sensors

Call up:
–
Settings
Machine settings
PP temperature
Set the reference temperatures for the
–
solutions and the dryer:
DEV 40 °C ± 0.3
BX 38 °C ± 2
STB 37 °C ± 3
Dryer 65 °C
Calibration of the temperature sensors :
–
When Readjust xxx is touched, a numeric
keyboard for the entry of the reference
temperature is opened. The field holds the
currently measured temperature of the sensor
to be calibrated. The sensor is calibrated after
entering a value and pressing OK.
Reset reference / Reset calibration are used
–
to enter the standard values of the data base.
4.28
2003-06-01 /PN 9008
Time in sec. Replenishment rates
27
27
3 x 18
2
90 ml/m
2
120 ml/m
2
240 ml/m
Operation
014
AGFA d-lab.3
