Operation

Print engine (PE), removing paper dust

Vacuum cleaner, brush
− Open the locking (1) of the PE.
− Pull out the PE (2) on the telescopic rails.
− Remove the guide plates (1) and (2):
To do so, press down the toggle on guide
plate (1) and press up on guide plate (2).
− Remove the paper dust with a vacuum
cleaner.
− Insert both guide plates again.
AGFA d-lab.3
Maintenance
2003-06-01 /PN 9008
dlab2005
dlabr095
8.9
