Weekly Maintenance; Film Carrier: Removing The Dust; Cleaning The Film Take; Cleaning The Film Chute - AGFA d-lab.3 Technical Documentation Manual

Operation

Weekly Maintenance

Film carrier: Removing the dust

− Remove the film carrier.
− Clean the window in the film carrier and insert
the carrier again.
Cleaning the film take-up
Purpose:
To remove dust and film abrasion which may
deposit on pulled-in films and may affect the
print results.
− Remove the film take-up and open it:
Pull the metal bracket (1) off to the front and
separate the two parts (2).
− Remove dust and film abrasion with a lint-free
cloth.
− Insert the film take-up again.

Cleaning the film chute

Purpose:
To remove dust.
− Open the front Printer door.
− Remove the dust from the film chute (1) with a
lint-free cloth.
− Close the Printer door.
AGFA d-lab.3
Maintenance
2003-06-01 /PN 9008
302B070
dlabr194
8.7
