Reproduction - AGFA d-lab.3 Technical Documentation Manual

Operation

Reproduction

Order configuration for image files which are to be
printed without automatic image improvement.
For foreseeable results the pixel size of the image
file must be known as it is printed 1:1 (image size)
with 400 dpi.
Image file with respect to the image format:
too big: information is cut
–
too small: white borders
–
approx. 3 times smaller: Image processing
–
errors may occur.
Printing is without preview; the configuration
cannot be changed. The print is printed in the
middle of a large size e.g. for CD inlays.
Also see dTFS preselection.
Select Film carrier and Film type
–
Set Configuration type Reproduction
–
Select Back print or set to OFF
–
PpF (no. of prints per frame)
–
Presetting = 1
(possible range 0...999)
Paper config. and Cut length for full frame
–
(FF) and Panorama
Save or Save as
–
AGFA d-lab.3
2003-06-01 /PN 9008
Settings
022_repr
4.75
