Scene - MDT Glass Push Button II Smart Series Technical Manual

Technical Manual Glass Push Button II Smart BE-GT2xx.01

4.3.4 Scene

Single-button function
The scene function makes it possible to call up and store scenes. If the memory function is activated,
this can be activated by a long key stroke.
The following figure shows the available settings:
Figure 30: Scene
The table below shows all available settings:
ETS-Text
Save scene
Scene number
Table 44: Scene
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
64
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[Default value]
no save
save
1-64
[1]
Comment
Release of saving the scenes;
the saving is carried out by a
long keystroke
Setting the respective scene
number
