Technical Manual Glass Push Button II Smart BE-GT2xx.01

4.1.3 Information screen

The following figure shows the basic settings for the information screen:
Figure 7: Basic Settings - Information Screen
The following table shows the basic settings for the information screen:
ETS-Text
Color of the orientation LEDs in
standby
Timeout for standby (0=never)
Standby display
Change standby display after
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
33
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[Default value]
Black, White...
[White]
0-60s
[20s]
display in one line
display in two lines
1-60s
[2s]
Comment
Adjusting the color of the
orientation display; This can be
used for day/night operation;
RGB states of the buttons are
used as orientation indicators
Sets the time between the last
touch of a button and switching
to standby mode
Setting whether the display is
shown in one or two lines
during standby
Sets the changeover time
between the activated status
elements
