Presentation - MDT Glass Push Button II Smart Series Technical Manual

Technical Manual Glass Push Button II Smart BE-GT2xx.01

4.3.2.5 Presentation

Single-button function
Two-button function
The display of the function "Send values" depends on the selected data point type. Depending on the
selected data point type, 1-4 different symbols and their color can be selected.
The following table provides an overview of the settings for the various data point types:
Datapoint type
2 Bit Switch control, DPT 2.001
1 Byte Percent, DPT 5.001
1 Byte Decimal fator, DPT 5.005
1 Byte Scene Number, DPT
17.001
2 Byte Temperature, DPT 9.001
2 Byte Brightness, DPT 9.004
3 Byte RGB value, DPT 232.600
Table 38: Presentation - Send values
Special presentation:
For certain data point types, a special presentation (see table above) is possible. In this presentation,
the status is shown on a larger scale on the display.
The following presentations are possible:
ETS-Text
Special display (DPT 5.001, DPT
5.005)
Special display (DPT 9.001)
Table 39: Send values - Special display
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
60
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Adjustable symbols
4 symbols can be set: 1 symbol
for each possible state
3 symbols can be set for the
ranges 0, 1 to 229 and larger
229. Therefore, the button
evaluates the information of the
"Status for display" object
Three icons can be set for the
ranges 0%, 1% to 90% and
greater than 90%. Therefore the
button evaluates the
information of the "Status for
display" object
1 fixed symbol can be set
1 fixed symbol can be set
1 fixed symbol can be set
1 fixed symbol can be set
Dynamic range
[Default value]
bar symbol
bar symbol with fan
value as text (0-100%)
value as text (0-255)
value as symbol + °C
value as symbol without
unit
value as symbol + K
Comment
Special presentation possible!
Additionally it is possible to
display the status value below
the symbol.
Special presentation possible!
Additionally it is possible to
display the status value below
the symbol.
Special presentation possible!
Comment
At the setti gs ar s
a d ar s ol ith fa , the
corresponding symbol is
displayed and the bar is filled
according to the current status.
With the settings "value as
text" the text is displayed large
on the display.
With the settings "value as
symbol" the text is displayed
large on the display.
ol
