Technical Manual Glass Push Button II Smart BE-GT2xx.01
The following table shows the available communication objects:
Number Name
0 Push button 1 / 1/2 –
Mode selection (HVAC
Mode)
1 Push button 1 / 1/2 –
State HVAC Mode
1 Push button 1 / 1/2 –
HVAC Status
Table 61: Communication objects - Mode selection
Presentation:
Single-button function
Two-button function
To each operating mode, a fixed symbol is assigned. The color of the symbol can be adjusted for any
operating mode:
Figure 40: Presentation - Mode selection
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
78
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Length Usage
1 Byte Switchover of operating mode
1 Byte Receives the status of the heating actuator /
temperature controller
1 Byte Receives the status of the heating actuator /
temperature controller
