Technical Manual Glass Push Button II Smart BE-GT2xx.01

4.4.2.1 Priority

The LED priority can force the status LED into a defined state and thus exceed the control via an
external / internal object or the key actuation.
The following figure shows the available settings for each of the active LEDs:
Figure 45: Setting - LED Priority
The table below shows all available settings:
ETS-Text
Object for priority
At day
Behavior at day
(value ON)
At night
Behavior at night
(value ON)
Table 71: Setting - LED Priority
As long as the LED priority is active, the parameterized state for the LED priority is kept and the LED
does not react to the "normal" control as described in 4.4.2 LED 1-12/A/B.
The following table shows the available communication objects:
Number Name
91 LED 1 Priority
Table 72: Communication object - LED Priority
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
86
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[Default value]
active if object LED
priority value = 1
active if object LED
priority value = 0
any color
permanent
blinking
any color
permanent
blinking
Length Usage
1 Bit Controlling the LED priority
Comment
Sets the polarity of the LED
priority
Color for an active LED priority
in day mode
Setting the lighting behavior for
an active LED priority in day
mode
Color for an active LED priority
in night mode
Setting the lighting behavior for
an active LED priority in night
mode
