Technical Manual Glass Push Button II Smart BE-GT2xx.01

4.2.4 Slap-/Cleaning function

The following figure shows the settings for the submenu of the Slap / Cleaning function:
Figure 13: Settings: Slap / Cleaning function
The following table shows the available settings:
ETS-Text
Cleaning function
Slap function
Send value
Individual time for long push of
button
Display behavior of LEDs
Blocking object
Table 20: Slap / Cleaning function
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
44
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[Default value]
not active
Cleaning = long button,
Slap = short button
Cleaning = short button
Slap = long button
switch Off
switch On
toggle
send value
nothing
DPT 2.001
Switch control
DPT 5.001 Percent
DPT 5.005
Decimal factor
DPT 17.001
Scene number
DPT 9.001 Temperature
DPT 9.004 Brightness
DPT 232.600 RGB value
not active
0,1s-30s
any color
not active
active
Comment
Activation of the Cleaning-/
Slap function and setting if
activation via short or long
keystroke
Setting of the function to be
executed at slap function
Setting the data point type if
slap function is set to "send
values"
Setting an individual time from
when a long keystroke is
detected
Indication behavior of the LEDs
when the slap function is active
Activation of the blocking
function for the slap function
