MDT Glass Push Button II Smart Series Technical Manual page 39

Technical Manual Glass Push Button II Smart BE-GT2xx.01
Standby display
no Standby
Table 15: Behavior of the device to an incoming message during operation
Standby display
no Standby
Standby in upper
keypad
Standby on full screen
Display off
Display off and
orientation-LED on
Table 16: Behavior when incoming message at standby and the operation switched off
Communication objects
The following table shows the available communication objects for the alarms/messages:
Number Name
115 Message 1 (highest
priority)
116 Message 2
117 Message 3
118 Message 4
119 Message text (lowest
priority)
Table 17: Communication objects - Alarms/Messages
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
39
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Incoming message during operation
No message is displayed but saved
Incoming message while Standby + Displaybrightness „Off via
brightness sensor
No message is displayed but saved
Brings display back to life (dark background lighting)
After the "timeout for standby" has expired, the backlight is
switched off again.
Otherwise as in Standby
Brings display back to life (dark background lighting)
After the "timeout for standby" has expired, the backlight is
switched off again.
Otherwise as in Standby
Like in Standby
Brings display back to life (dark background lighting)
After the "timeout for standby" has expired, the backlight is
switched off again.
Otherwise as in Standby
Length Usage
1 Bit Triggering a message
1 Bit Triggering a message
1 Bit Triggering a message
1 Bit Triggering a message
14 Byte Triggering a message; Send any message text
