Technical Manual Glass Push Button II Smart BE-GT2xx.01

4.6 Temperature measurement

Function only available for Glass Push Button II Smart with temperature sensor
The following figure shows the menu for temperature measurement:
Figure 50: Settings - Temperature measurement
The table below shows all available settings:
ETS-Text
Temperature measurement
External temperature value
Send measurement value
cyclic
Send measurement value at
change
Adjustment value for
internal temperature
Temperature for upper
message value
Temperature for lower
message value
Table 76: Settings - Temperature measurement
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
90
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[Default value]
not active
active
not active (internal 100%)
external 10% (internal 90%)
external 20% (internal 80%)
...
external 90% (internal 10%)
not active
1min – 4h
not send
0,1°C – 5°C
-5K-5K
[0 K]
not active
20°C – 45°C
not active
3°C – 30°C
Comment
Activation of temperature
measurement
Activation of an extension for
temperature measurement
Activation of the cyclic
sending for the temperature
measurement value
Activates the sending of the
current temperature value
from a certain change
Increase / decrease the
internal temperature to
correct the measured
temperature
Activation of a message when
a certain temperature is
reached
Activation of a message if the
temperature falls below a
certain temperature
