Technical Manual Glass Push Button II Smart BE-GT2xx.01
Presentation:
Single-button function
Two-button function
The color temperature is represented by a special symbol. The current status is evaluated by the
button and the current position is displayed with an arrow on the special symbol.
The special symbol is shown below:
ETS-Text
Color temperature
Table 59: Special symbol - Color temperature
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
75
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Symbol
Comment
