Technical Manual Glass Push Button II Smart BE-GT2xx.01
Color of message text
Indicate a message via LEDs
Table 13: Messages/Alarms
The message behavior depends on the parameter "Standby display at day / night". The different
behaviors are shown below:
Standby display
no Standby
Standby in upper
keypad
Standby on full screen
Display off
Display off and
orientation-LED on
Table 14: Behavior of the device to an incoming message during standby
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
38
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Any color
No
Yes
Incoming message during standby
No message is displayed but saved
Message is displayed on upper button pair and the upper LEDs
change between parameterized color and black at 600ms pulse
At the same time, the parameterized color is set to double
brightness in order to increase the signal effect
The message is only acknowledged by pressing to one of the
upper buttons.
A keystroke on the middle and lower buttons performs the
displayed switching functions
Message is displayed in the middle of the screen and all LEDs
change between parameterized color and black
At the same time, the parameterized color is set to double
brightness in order to increase the signal effect.
The message is acknowledged by pressing to any key
No message is displayed during standby but saved.
The message with the highest priority is indicated by the
keystroke after standby
The displayed messages are acknowledged by means of further
key strokes
Message is displayed in the middle of the screen and all LEDs
change between parameterized color and black
At the same time, the parameterized color is set to double
brightness in order to increase the signal effect.
Message is displayed in the middle of the screen and all LEDs
change between parameterized color and black
At the same time, the parameterized color is set to double
brightness in order to increase the signal effect.
After the "timeout for standby", the LEDs will stop flashing and
the message dispappears.
If any button is pressed after the LEDs have stopped flashing, the
message with the highest priority is displayed again. Further
keystrokes acknowledge the messages
Setting of the color for the
message text
Setting if the LEDs should flash
at an active message
